iPhthtone 17 Pro Max
Summary
6.9″
Super Retina XDR display
ProMotion technologyAlways-On display
Dynamic Island
Aluminum unibody
Action button
Camera Control for faster access
to photo and video tools
Ceramic Shield 2 front,
3x better scratch resistance
Ceramic Shield back
Water resistant to a depth of
6 meters for up to 30 minutes2
A19 Pro chip
6-core CPU
6-core GPU with
Neural Accelerators
Neural Accelerators
16-core Neural Engine
Hardware-accelerated ray tracing
Up to 39 hours video playback3
18MP Center Stage front camera
Tap to zoom and rotate
Center Stage for photos
Ultra-stabilized video
Dual Capture
Center Stage for video calls
48MP Pro Fusion camera system
48MP Fusion Main 48MP Fusion
Ultra Wide 48MP Fusion Telephoto
Super-high-resolution photos (24MP and 48MP)
Next-generation portraits with
Focus and Depth Control
Macro photography
Dolby Vision up to 4K at 120 fps
Latest-generation
Photographic Styles
Photographic Styles
MagSafe wireless charging up to
25W with 30W adapter or higher
25W with 30W adapter or higher
Compatible with MagSafe cases, wallets, wireless chargers, and more
Capacity
256GB
512GB
1TB
2TB
Display
Super Retina XDR display
6.9-inch (diagonal) all-screen OLED display1
Dynamic Island
ProMotion technology with adaptive refresh rates up to 120Hz
Always-On display
HDR display
2868-by-1320-pixel resolution at 460 ppi
2,000,000:1 contrast ratio (typical)
True Tone display
Wide color display (P3)
Haptic Touch
1000 nits max brightness (typical)
1600 nits peak brightness (HDR)
3000 nits peak brightness (outdoor)
1 nit minimum brightness
Size and Weight
Height6.43 inches (163.4 mm)
Width3.07 inches (78.0 mm)
Depth0.34 inch (8.75 mm)
Weight8.22 ounces (233 grams)
Splash, Water, and Dust Resistant
Rated IP68 (maximum depth of 6 meters up to 30 minutes) under IEC standard 60529
Apthtple Intelligence
Apthtple Intelligence is integrated across your apps and experiences to help you communicate, express yourself, and get things done effortlessly. With groundbreaking privacy protections, it gives you peace of mind that no one else can access your data — not even Apthtple.
Chip
A19 Pro chip
6-core CPU with 2 performance and 4 efficiency cores
6-core GPU with Neural Accelerators
16-core Neural Engine
Hardware-accelerated ray tracing
Camera
48MP Pro Fusion camera system
48MP Fusion Main
48MP Fusion Ultra Wide
48MP Fusion Telephoto
Second-generation sensor-shift optical image stabilization (Fusion Main)
3D sensor-shift optical image stabilization (Fusion Telephoto)
Adaptive True Tone flash
Photonic Engine
Deep Fusion
Smart HDR 5 for photos
Next-generation portraits with Focus and Depth Control
Portrait Lighting with six effects
Night mode
Latest-generation Photographic Styles
Macro photography
Spatial photos
ProRAW
Video Recording
4K Dolby Vision video recording up to 120 fps (Fusion Main), up to 60 fps (Fusion Ultra Wide, Fusion Telephoto)
Cinematic mode for recording videos with shallow depth of field (up to 4K Dolby Vision at 30 fps)
Dual Capture (up to 4K Dolby Vision at 30 fps)
Action mode (up to 2.8K Dolby Vision at 60 fps)
Spatial video recording at 1080p at 30 fps
ProRes video recording up to 4K at 120 fps with external recording
ProRes RAW
Academy Color Encoding System
Apthtple Log 2 video recording
Genlock support
Macro video recording, including slo‑mo and time‑lapse
Slo‑mo video support for 1080p up to 240 fps and 4K Dolby Vision up to 120 fps (Fusion Main)
QuickTake video (up to 4K at 60 fps in Dolby Vision HDR)
Second-generation sensor-shift optical image stabilization (Fusion Main)
3D sensor-shift optical image stabilization (Fusion Telephoto)
3D sensor-shift optical image stabilization (Fusion Telephoto)
Spatial Audio and stereo recording
Studio-quality four-mic array
Wind noise reduction
Audio Mix
Front Camera
18MP Center Stage front camera
18MP photos
Center Stage for photos
Dual Capture
Center Stage for video calls
Ultra-stabilized video
Photonic Engine
Deep Fusion
Smart HDR 5 for photos
Next-generation portraits with Focus and Depth Control
Night mode
Latest-generation Photographic Styles
4K Dolby Vision video recording up to 60 fps
Cinematic mode up to 4K Dolby Vision at 30 fps
ProRes video recording up to 4K at 60 fps with external recording
Slo-mo video support for 1080p at 120 fps
QuickTake video (up to 4K at 60 fps in Dolby Vision HDR)
Cinematic video stabilization (4K, 1080p, and 720p)
Power and Battery
Built-in rechargeable lithium‑ion battery
MagSafe, Qi2, and Qi wireless charging
Video playbackUp to 39 hours
Fast-charge capableUp to 50% charge in 20 minutes with 40W adapter or higher (available separately) paired with USB-C charging cableVideo playback (streamed)Up to 35 hours
Up to 50% charge in 30 minutes with 30W adapter or higher paired with MagSafe Charger (both available separately)
Peace of Mind
Emergency SOS via satellite
Crash Detection
Roadside Assistance via satellite
Messages via satellite
Cellular and Wireless
5G (sub-6 GHz and mmWave) with 4x4 MIMO
Gigabit LTE
Wi-Fi 7
Bluetooth 6
Apthtple second-generation Ultra Wideband chip
Thread networking technology
Precision dual-frequency GPS (GPS, GLONASS, Galileo, QZSS, BeiDou, and NavIC)
VoLTE
NFC with reader mode
Express Cards with power reserve
Wi-Fi calling
Secure Authentication
Face ID
Enabled by TrueDepth technology in the Center Stage front camera
Siri
Get help with everyday tasks likesending messages, setting reminders,and more
Activate hands-free with only your voiceusing "Siri" or "Hey Siri," or use Type toSiri
Protected by the strongest privacy ofany intelligent assistant
Powered by Apthtple Intelligence, Siri ismore natural and helpful4
Sensors
LiDAR Scanner
High dynamic range gyro
High-g accelerometer
Proximity sensor
Dual ambient light sensors
Barometer
SIM Card
Dual eSlM19Two active eSlMs; stores eight or moreeSlMs
Supports advanced eSlM technologyfor more convenience and security (notcompatible with physical SlM cards)
In the Box
- iPththone
- USB-C Charge Cable (1 m) and Power Adaptor
- Documentation
